IG Standard Duty Steel Eaves Lintel 1950mm x 134mm - L1/E50

The IG L1/E 50 Standard Eaves Lintel is specifically designed to provide structural support over openings at the eaves level, such as above windows or doors. It accommodates cavity widths ranging from 50mm to 85mm and features a shortened outer flange, ensuring that the soffit board can fit snugly against the window frame. It’s important to note that brickwork cannot be placed on the outer flange of the eaves lintel. Instead, masonry is built on the inner leaf only. This lintel helps ensure even distribution of load in these critical areas of construction. Key Features : Cavity Width: Suitable for cavity widths of 50-85mm. Designed for Eaves Support: Provides structural support over openings at the eaves level. Shortened Outer Flange: Allows soffit board to be positioned tightly against the window frame. Masonry Application: Masonry is built on the inner leaf only; outer flange cannot support brickwork. Durability: Manufactured from high-quality steel for reliable performance. Ease of Installation: Simplifies construction at eaves levels with precise fit and design.
